Description
CURT 45297 Chrome Class 3 Trailer Hitch Ball Mount, Fits 2-Inch Receiver, 7,500 lbs, 1-Inch Hole, 6-Inch Drop
CURT class 3, or standard-duty, ball mounts are a step up from classes 1 and 2. They feature a 2″ x 2″ shank and have a higher weight capacity for towing heavy-duty trailers, including utility trailers, boat trailers, campers, single-horse livestock trailers and most recreational vehicle trailers. With class 3 trailer hitches being the most common type of trailer hitch for pickup trucks and SUVs, the class 3 ball mount, by association, is an excellent complement to this trailer hitch and these larger vehicles (NOTE: Never exceed the lowest weight capacity of any towing component; i.e. the vehicle, hitch, trailer, etc).This particular class 3 ball mount can be used in the drop position to provide a drop of 6″, a gross trailer weight capacity of 7,500 lbs. and a tongue weight capacity of 750 lbs. It can also be flipped to provide a rise of 4″, a gross trailer weight capacity of 6,000 lbs. and a tongue weight capacity of 600 lbs. It features a length of 9-1/4″. Class 3 ball mounts are CNC-formed and robotically welded to ensure unwavering precision and dependable strength in each and every unit. We mechanically descale each one to provide a smooth surface for a long-lasting finish. This class 3 ball mount comes with a bright chrome-plated finish to protect against corrosion, scratches, UV damage and more to give it the thick skin it needs to face the road ahead.
- Fits trailer hitches with a 2″ x 2″ receiver tube opening
Information:
Fits trailer hitches with a 2″ x 2″ receiver tube opening
Application Summary:
| Year | Make/Model |
|---|---|
| CURT | 45297 Chrome Class 3 Trailer Hitch Ball Mount, Fits 2-Inch Receiver, 7,500 lbs, 1-Inch Hole, 6-Inch Drop |
Specification
| Attributes | |
| ASIN | B0007LZXFO |
| California Proposition 65 | Yes |
| Container Cases Qty – XA | 1050 |
| Container Pallet Qty – XA | 15 |
| Container Type – XA | 40GP |
| Container Unit Qty – XA | 2100 |
| Container Volume Cubic Feet – XA | 0.00000 |
| Container Volume Cubic Meter – XA | 0.00000 |
| Container Weight KG – XA | 10316 |
| Container Weight Lbs – XA | 22695 |
| Country of Origin (Primary) | CN |
| Drop | 6 IN, 6.000 in. |
| Drop (in.) | 6.000 in. |
| Finish | Chrome |
| Finish – XA | Chrome, Chrome |
| GTIN | 00612314447008 |
| GTW/TW Ball Drop | 7,500 LB / 750 LB, 7,500 LB / 750 LB |
| GTW/TW Ball Rise | 6,000 LB / 600 LB, 6,000 LB / 600 LB |
| Harmonized Tariff Code (Schedule B) | 8708998180 |
| Hazardous Material Code | N |
| Item Class – XA | OBS, OBS |
| Item Height – XA | 0.000, 0.000 |
| Item Length – XA | 0.000, 0.000 |
| Item Width – XA | 0.000, 0.000 |
| Life Cycle Status Code | Available to Order |
| Long Description | 7500 GWT 6 In Drop With 8 1/4 In Bar Chrome |
| Master Case Height Inches – XA | 5.625 |
| Master Case ITF14 | 20612314447002 |
| Master Case ITF14 – XA | 20612314447002 |
| Master Case Length Inches – XA | 15.500 |
| Master Case Qty – XA | 2 |
| Master Case Volume Cubic Feet – XA | 0.00000 |
| Master Case Weight Lbs – XA | 21.000 |
| Master Case Width Inches – XA | 5.375 |
| Material – XA | Blank |
| Mount Type Description – XA | Blank |
| NAFTA Preference Criterion Code | B |
| Overall Length | 8.250 in. |
| Overall Length (in.) | 8.250 in. |
| Pallet Case Per – XA | 70 |
| Pallet Case Per Layer – XA | 14 |
| Pallet Cases Per – XA | 70 |
| Pallet Cases Per Layer – XA | 14 |
| Pallet Layer of Cases – XA | 5 |
| Pallet Qty – XA | 0.000 |
| Pallet Total Height Inches – XA | 33.125, 33.125 |
| Pallet Total Weight Per – XA | 1513.000, 1513.000 |
| Parcel Allowed – XA | Yes, Yes |
| Product Weight – XA | 0.000, 0.000 |
| Rate Class – XA | 70.0, 60.0 |
| Receiver Tube Size | 2 IN, 2.000 in. |
| Retail Height – XA | 3.000, 3.000 |
| Retail Length – XA | 16.000, 16.000 |
| Retail Width – XA | 6.000, 6.000 |
| Rise | 4 IN, 4.000 in. |
| Rise (in.) | 4.000 in. |
| SDR Required Flag | N |
| Sales Family Code – XA | ACCES, ACCES |
| Sales Family Description – XA | ACCESSORIES, ACCESSORIES |
| Sales Group Description – XA | BALL MOUNT, BALL MOUNT |
| Shipping Weight – XA | 10.000, 10.000 |
| Side Application Type Description – XA | Blank, Blank |
| Style | Fixed |
| Tariff 301 – XA | Yes, Yes |
| Truckload Cases Qty – XA | 1120, 1120 |
| Truckload Dom Pickup Location – XA | Eau Claire, Wi, Eau Claire, Wi |
| Truckload Pallets Qty – XA | 16, 16 |
| Truckload Units Qty – XA | 1120, 1120 |
| Truckload Volume Cubic Feet – XA | 87.00000, 87.00000 |
| Truckload Weight – XA | 23090, 23090 |
| Warranty | Limited Lifetime Warranty (One-Year Finish, One-Year Parts), Limited Lifetime Warranty (One-Year Finish, One-Year Parts) |
